Identificador: 617
Abierta
.jpg)
Descripción
PARTE: 2SW-LS4-36 - MESA DE TIJERA - PLATAFORMA 36" X 72"
Nuevas con garantía
Hechas en USA
Medidas y capacidad para manejar 1 bulto de MDF, Aglomerado, etc. a la vez para alimentar maquinaria para la madera,
CAPACITY: 4,000 lb. uniform load.
PLATFORM: 36" x 72" smooth plate with 4" Fork Risers.
BASE FRAME: 24" x 48" with lag plates and maintenance device.
LOWERED HEIGHT: 6-3/4"
VERTICAL TRAVEL: 36"
RAISED HEIGHT: 42-3/4"
ELEVATING TIME: 44 seconds (approx.)
LOWERING TIME: Adjustable with pressure compensated flow control.
POWER UNIT: Internally mounted with 1.0 HP TENV electric motor (includes a power cord, approx. 9' in length ) and .85 GPM hydraulic pump, valving, and reservoir filled with oil.
PRIMARY VOLTAGE: 115/1/60
CONTROL VOLTAGE: 115/1/60
CONTROL NEMA: 1 footswitch with safety cover. Includes 10 ft of straight cord.
ACTUATION: Two 3-1/2" low pressure cylinders with chrome plated rod, power up/gravity down.
BUSHINGS: All pivot points equipped with Teflon lined bushings. Leg rollers have Southworth exclusive wear indicators.
FINISH: Dark green self-priming machinery enamel with platform painted beige.
WARRANTY: Parts will be covered for two years upon receipt and approval of application information (see Southworth warranty for details).
WEIGHT: 900 lb. (approx.) - Freight class #70
Pago y Devoluciones
- Forma de pago
- Transferencia/Deposito Bancario
Publicar mensaje
Ingresar to ask the seller a question.
AMXmachinery
PUNZONADORA - HIDRAULICA - 40 TONS
PARTE: 12325 - PUNZONADORA - HIDRAULICA - 40
TONS
USADA - BUENAS CONDICIONES
Brand: Greenerd
Size: Length: 70 in.
Width: 44 in. Height: 96 in.
Country of
Manufacture: N/A
Weight (lbs, oz): 5934,
Tested and runs PLC
Lost its program
Safety's were
bypassed to test machine
Open height is
18-5/8"
Closed height is
6"
230/460V 3 Phase
Table Size
36"x16"
AMXmachinery
SIERRA CUBIERTAS DE COCINA
PARTE # 12026 – SIERRA CUBIERTAS DE COCINA – EDGETECHUsada - Checada y probada
AMXmachinery
LIJADORA DE BANDA - MESA MOVIBLE – 2 BANDAS – MOTOR 5 HP - MESA 30”X 96” - USO RUDO
PARTE:
2DO-PMC-HD2 –
LIJADORA DE BANDA - MESA MOVIBLE – 2 BANDAS – MOTOR 5 HP
- MESA 30”X 96”
USO RUDO
Nueva con garantíaHeavy
duty welded structure. They feature dust hoods on both sides, a table with
steel rollers and virtually wear free balanced and quiet running aluminum
pulleys. All models are equipped with a magnetic starter (overload protection)
and belt guards. Maximum
Part Length:Pressure
Pad Traveling Bar: 96"Pressure
Pad Traveling Bar Contact Wheel Ass...
AMXmachinery
AFILADOR SIERRA CINTA 30-40 MM
PARTE # 2LSL-99990000506 - AFILADOR AUTOMATICO - ANCHOS 30-40 MMNUEVA CON GARANTIAAFILA SIERRAS DESDE 30 A 40 MM ANCHO EN 1 SOLA PASADAPARA DIENTES ENTRE 18 A 23 MMThe bandsaw blade grinder shall only be used for bandsaw blades with hardened saw teeth. The pitch shall be 25 mm and the bandsaw blade width shall be 32 mm.Motor Data, Grindlux 4000Voltage, V: 12Speed, rpm: 2800Peripheral speed, m/s: 22Power, W: 90Amperage, A: 7.5Grinding disc, mm: 150 x 6 x 16Fuse, A: 12 / 0.25Weight: 18.1 lbs. (8.2...
