Identificador: 1032
Abierta
PARTE: 12173 - DOBLADORA DE TUBOS – HIDRAULICA - CAPACIDAD DIAMETRO 4-1/2”
AMXmachinery
Descripción
PARTE: 12173 - DOBLADORA DE TUBOS – HIDRAULICA - CAPACIDAD DIAMETRO 4-1/2”
Usada – Buenas condiciones, Revisada y Checada
Capacities:
Non-ferrous tubing: 4.5" x .17" - Y.P. to 25,000 PSI
Mild steel tubing: 4.5" x .11" - Y.P. to 35,000 PSI
Stainless steel tubing: 4.5" x .065" - Y.P. to 60,000 PSI
Steel pipe: 3.5" x .24" schedule 80
Maximum radius: 18"
Tube length over mandrel: 10'
Maximum working pressure: 2200 PSI
Bending arm speed: 3 RPM
EQUIPPED WITH:
Hydraulic mandrel extractor
XHQG-30 PLC touch screen control with
bending data storage up to 50 parts
with 12 bends - jog - step -
auto function selection
Mandrel rod holder assembly
Pressure die assist, pressure die holder,
wiper die holder & clamp die holder
Swinging arm safety stop
Automatic oil lubrication
Hydraulic pump, driven by
20 HP 220 volts 3 ph 60 Hz. motor
Weight approx. 13,000 lbs.
Overall dimensions approx. 207" L-R x 73" F-B x 57" H
