PARTE: 11753 - ENGOMADORA DE 54”
3 - ENGOMADORA DE 54”. ENGOMADORA MARCA IND. G.H.
ACCIONADA POR 2 RODILLOS DE 50” DE LARGO Y 7 ½” DE DIAMETRO, CON ELEVADOR
OPERADO CON CONTROL BARS, MOTOR IZQUIERDO CON PERILLA MANUAL Y ELECTRICA,
CONTROL DE MANO DERECHA, ENGOMADO EN MEDIDAS DE 0.8 MM A 2.5 PULGADAS DE GROSOR
CON UNA CAPACIDAD DE PROCESO DE 110 PIES POR MINUTO, MOTOR DE 5 HP Y
MOTORREDUCTOR DE 2.5 HP
PARTE: 12105 – SIERRA INGLETEADORA – DOBLE – CTDUsada – Buenas condiciones230/460V, 60 Cy, 3 PhaseMotor: 3 HP, 3450 RPM.09 Cubic Meters At 5.2 KG/ CM Squared Based on 10 Strokes per MinuteSaw Heads Swivel From 90 Degrees-45 Degrees Toward Each-Other with Degree Markings and Stops at 90 Degrees-45 Degrees8' Centers, Traveling Right Hand Carriage On Rack and PinionSaw Arms-Pivot Brackets are Cast Iron10" Blade-2" (51MM) x 4-7/8" (124MM)12" Blade-2.5" (64MM) x 5-3/8 (136 MM)Weight: 2000 LBS...
PARTE:
SIL-DC-WJ6P - CANTEADORA 6" - MOTOR 1.5 HP
Motor: 1.5 H.P., 110/220V., 60Hz, 1 ó 2 Fases
Altura De La Mesa: 32”
Tipo De Empaque: 1 caja
Peso De La Máquina: 93 Kg.
Máx. Profundidad De Corte: 6” x 1/8”, 3” x 1/4”
Capacidad Máx. De Traslape: ½”
Inclinación De La Guía: 45°, 90° y 135°
Cantidad De Cuchillas: 3 pzas.
Ancho Máximo De Desbaste: 6"
Dimensiones De La Mesa De Entrada: 22” x 7-1/2”
