Identificador: 1927
Abierta
Descripción
PARTE: 4GR-GAZ62 - ASTILLADORA PARA MADERA - 15, 20, 25 HP
NUEVA CON GARANTIA
Valuable substance shredders shred materials such as wood, cardboard, plastic and many others economically and effectively.
Can be adjusted according to customer specific requirements for throughput volume, material to be processed, etc.
Compact and designed for high performance.
Details:
Profile rotor with welded knife carriers
Transmission and motor
Hydraulics
Screen basket
Switching cabinet / SPS control
Protected rotor bearing
Technical data:
GAZ 62
Feed opening (mm): 600 x 800
Hopper capacity (cbm): 0,6 m³
Throughput: Material and screen dependent
Rotor-Ø (mm): 252
Rotorlength (mm): 600
Rotor speed (rpm): 60 - 100
Power required (kW): 11/15/18,5
Tools: 14 knives
Screen perforation (mm): 10 - 40
Suction piece-Ø (mm): 160 mm
Air speed (m/sec.): 28
Weight (approx. kg): 1.300
Function
Material is fed through the hopper in front of a hydraulically operated drawer, which pushes the material load-controlled onto the turning rotor. The material is shredded between the rotor knives and a fixed counterknife.
The drawer has stripping bars that prevent material from entering between the drawer and machine housing. The screen hole with different perforation diameters determines the size of clippings or shavings. Produced shavings can be removed from the machine with the suction device or spiral conveyor. Once the material is shredded, the machine will automatically shut off.
PLC option for fully automated operation (upon request)
Special designs upon request.
