PART: 2TA-TG-9330-E - PROFILE KNIFE GRINDER
NEW WITH WARRANTY
FEATURES:
- Economical model for small shop.
- Work table back to front, left to right is moved on linear bearing cross roller rail sets, accuracy and durability.
- Grinding wheel head is micro adjustable and accurate. 2 HP variable speed control motor for powerful grinding.
- Easy setup template holder for accurate copy tracer.
- Knife-edge angle is adjusted by dovetails are grooved; grinding center is never changed, no matter what the angle is.
- Water splash guard and coolant tank are made with stainless steel to protect from rust.
- Easy and efficient to operate.
- Heavy sheet metal cabinet stand and cast iron body.
- High precision and durability.
|
SPECIFICATIONS |
2TA-TG-923 |
2TA-TG-9330 |
|
Grinding Capacity |
||
|
Cutter (Dia. x W) |
12" x 10" |
12" x 12" |
|
Grinding Wheel Size |
7.5", 60mm Dia |
8" x 2¼" |
|
Grinding Head Travel |
13" |
13" |
|
Grinding Wheel Speed |
1500-4500 RPM (Var) |
1500-2900 RPM (Var) |
|
Grinding Wheel Motor |
2 HP |
2 HP |
|
Coolant Pump Motor |
1/8 HP |
1/8 HP |
|
N.W. (LBS) |
1050 LBS |
1100 LBS |
|
G.W. (LBS) |
1450 LBS |
1500 LBS |
Pago y Devoluciones
- Forma de pago
- Visa/Mastercard/American Express
Publicar mensaje
Ingresar to ask the seller a question.
AMXmachinery
CEPILLO 2 LADOS CABEZALES HELICOIDALES INSERTOS NORTHTECH
PARTE: 12074 – CEPILLO 2 LADOS – CABEZALES HELICOIDALES INSERTOS - 24" ANCHO - NORTHTECHUSADO - EN MUY BUENAS CONDICIONESUSO RUDOCABEZAL SUPERIOR 30 HPCABEZAL INFERIOR 25 HPMOTOR ALIMENTACION: 5 HPCABEZALES 5000 RPMVELOCIDAD VARIABLE 25 - 95 FT/MIN ESPESOR DE TRABAJO 10 - 155mm (3/8” - 6-1/2”)15” min working length - 24” maximum widthMANUFACTURA 2005FEATURES:Carpet feeding spike system with 1100 spikesMechanical variable speedDigital control panel with 3 amp metersChrome bed ...
AMXmachinery
PARTE: AMX-10164 - EXTRACTOR DE PARED - EN ALUMINIO - 19” ANCHO X 19” ALTO X 16” FONDO
PARTE: AMX-10164 - EXTRACTOR DE PARED - EN ALUMINIO -
19” ANCHO X 19” ALTO X 16” FONDO
USADO - MUY BUENAS CONDICIONES
MARCA: FLOAIRE
MODELO: DR12H
MEDIDAS: 19” ANCHO X 19” ALTO X 16”
FONDO
MOTOR: 0.18 HP, 115V, 1 FASE, 60 HZ
FLA: 2.0Video: https://vimeo.com/870538960
AMXmachinery
HACHA HIDRAULICA
PARTE: 2AR-67090 - HACHA HIDRAULICA – CAPACIDAD MAXIMA 18” LARGO X 6-1/2” DIAMETRO – 10 TONNueva con garantíaManually operatedExtra long handles for plenty of leverageCompact size for convenient storageProduct Measures: Width: 8-1/4 in. x Length 42-1/8 in. x Height: 9-3/4 in.Product Weight: 80.50 lb.Shipping Weight: 95.20 lb.Splitting Force (tons): 10Travel length (in.): 8-1/16 in.
AMXmachinery
LIJADORA DE BANDA Y DISCO DE BANCO
PARTE # SIL-DC-BDS69-B - LIJADORA DE BANDA Y DISCONUEVA CON GARANTIAMOTOR: 1 HP, 110V, 60 Hz, 1 FASEDIMENSIONES DE LA MESA: 7" X 16"DIMENSIONES DE LA MESA DEL DISCO: 6-1/2" X 10"DIAMETRO DEL DISCO LIJADOR: 9"DIMENSIONES DE LA BANDA LIJA: 6" X 48"INCLINACION DE LA MESA: 45 GRADOSPESO: 35 KGSEMPAQUE: 1 CAJA
